ASTEC Power Supply Assembly 5136907
| 5136907 | |
| Computed Tomography (CT) | |
| Other Computed Tomography (CT) | |
| GE HealthCare | |
| 5136907 | |
Add to Wish List
Login To Shop
Please select date
Second Opinion Approval Needed
Enter your approval number and submit to add item(s) to cart.
Approval Number
Please enter approval number
OR
Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.
If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.
Second Opinion Approval Needed
Select your approver's name and submit to add item(s) to your cart
Approver Name
Please Select Approver Name
OR
Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.
If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.
Features
- Overvoltage/Overcurrent protection
- Voltage adjustment on all outputs
- Power factor correction
- Short circuit and reverse voltage protection
Product Overview
This low voltage power supply module converts AC input voltage into multiple DC voltages. A main component of this assembly is a configurable AC-DC power supply with 4 different output modules. Two single output modules can be used to withdraw 35 A and 15 A on 5 VDC and 24 VDC outputs respectively, the 5 VDC dual output module can be used to withdraw 10 A on each output and the 15 VDC triple output module can be used to withdraw 1 A on each output. This power supply comes with built-in overload, reverse and short-circuit protection. The output voltage can be adjusted by a voltage screw on the module. This power supply has built-in Power Factor Correction (PFC) which increases power efficiency. The heat dissipation in this power supply is controlled and managed by the built-in forced air fan. The assembly comes with a support base with mounting provisions, connector supports, screws, input/output cables and fuses.
