Pyxis Battery Pack

5450061
5450061-2
Ultrasound
LOGIQ S8
GE Healthcare
5450061
Add to Wish List
Login To Shop
Login To Shop
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.

Taxes extra, details on the checkout page

Features

  • High energy density
  • UL2054, IEC62133, FCC and UN38.3 certified
  • Flammability rating UL 94V-0
  • Communication interface for status identification

Product Overview

The Pyxis Battery Pack is a component that is used in Medical diagnostic ultrasound imaging equipment, which uses this battery pack as a backup power source. The lithium-ion battery provides power when the AC power source is interrupted. Lithium-ion batteries last longer than conventional batteries and do not require replacement as often. The lithium-ion technology used is significantly less hazardous to the environment than the lithium metal technology used in some other batteries (such as watch batteries). This particular battery comes along with the protection circuit for detecting function of overcharge, over discharge and over voltage and thermal protection circuits as well as a SMBus for communication. This serial bus helps to read the set of battery parameters in a regular interval as part of maintenance. A thermistor present in the pack helps to ensure thermal protection, its resistance gradually varies in terms of change in temperature. The battery pack is capable of continuous charging at 14.4V and a 6000mA maximum current and it is capable of continues discharge at 12V, 20 Amp (max). It includes a polyethylene terephthalate (White) material label on top for easy identification as well to add regulatory markings.

Compatible Products

LOGIQ S8

LOGIQ S8

Voluson S6

Voluson S6

Voluson S8

Voluson S8

Substitute Parts (price may vary):

Below is more information on the equivalent parts. Parts without a hyperlink are listed for reference only and are not available for purchase online.

Equivalent partPart Details
5450061-2 Polaris-Maru Battery Pack
