Bag Arm - Lower Assembly

1407-7012-000
Anesthesia Delivery
Aespire
GE HealthCare
N/A
Add to Wish List
Login To Shop
Login To Shop
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.

Taxes extra, details on the checkout page

Features

  • Easy to assemble and disassemble
  • Easy to rotate
  • Good surface finish
  • Highly compactable for anesthesia machines

Product Overview

The Bag Arm is intended to act as a closing switch of the ventilator path. The bag arm consists of upper and lower assemblies. The bag arm lower assembly has a narrow end and a wide end. The bag arm and its sub components are made up of stainless steel. The lower assembly consists of a spring, flat washer, nut, M6 screw and a swivel mechanism. A spring is attached to the M6 screw through the center of the bag arm and tightened with the help of a flat washer and a nut. The upper bag arm assembly will be inserted into the lower bag arm assembly. A swivel mechanism is provided to offer flexibility in rotating the arm. This assembly is being used in Aestiva anesthesia machines. Other applications are ARC Airway Gas Module, ARC S/5 Monitor Anesthesia, ARC ADU and ARC Aestiva 7100.

Compatible Products

Aespire

Aespire

Aisys

Aisys

Avance

Avance

S/5 Aespire

S/5 Aespire
